Features

EasyFresh

The guarantee of market freshness in the home is our EasyFresh-Safe. Whether it’s unpackaged vegetables or fruit, this ensures optimal storage for everything. Thanks to the air-tight closure, the food causes the humidity in the safe to rise. This keeps the food fresh for a long time.

NoFrost

When you open your freezer, you want to see frozen food – and certainly not ice and frost. NoFrost protects the freezer compartment from unwanted icing, which consumes a lot of energy and can be expensive. NoFrost means no more tedious and time-consuming defrosting of the freezer compartment, more time for other things – and saving money.

DuoCooling

DuoCooling uses two completely separate refrigeration circuits to ensure no air is exchanged between the fridge and freezer compartments. The food neither dries out nor is odour transferred. This means throwing less away, shopping less often, but saving more and greater enjoyment.

Touch display

Fingertip control: the touch display enables easy and intuitive operation of your Liebherr. All functions are clearly arranged on the display. By gently tapping a finger, for example, you can easily select the functions or check the current temperature of your refrigerator.

SmartSteel rear wall

The rear wall in elegant SmartSteel gives your Liebherr a stylish look and feel. Your food will also love SmartSteel as stainless steel is food-safe and hygienic. SmartSteel also reduces the visibility of fingerprints – making the appearance even more pleasing.

SoftSystem

From breakfast to a midnight snack – a fridge needs to be open and closed on many occasions. And your Liebherr makes this is a lot of fun. With the SoftSystem, your fridge door closes softly and safely, and in a way which is pleasantly quiet and light. Bottles stored in the inside door remain securely in place – nothing rattles or wobbles.

Space for baking tray

Do you want to keep that home-baked fruit pie fresh? Or maybe a prepared pizza to be baked later on? If so, simply slide your baking tray into your Liebherr ¬- it has plenty of space for storing a baking tray. Really convenient – you can slide the baking tray in and out when the door is opened at 90°.

Convenient height for adjustment shelves

o you need a large container to go in the fridge? If so, simply adjust the heights at which you insert the glass shelves. The convenient height adjustment means this can be done quickly and individually – even with food stored on the shelves.

Vario Space

Looking for somewhere to safely store a multi-tiered ice cream cake until the summer party? No problem for your Liebherr freezer: it knows that sometimes you just need more space. Thanks to VarioSpace, you can simply remove individual freezer drawers – and voilà: here’s your extra-high storage space!

Easy fresh with integrated drawer runner

The integrated drawer slides with pull-out stop mean your EasyFresh safe can be opened and closed really easily. A further plus in terms of convenience: the running rails close the safe reliably. This means your chilled food is always stored under optimum conditions.

Party mode

Now you’re ready to receive guests – because even your Liebherr is in the mood for a party. In PartyMode, functions such as SuperCool and/or SuperFrost are activated. After 24 hours, your Liebherr goes back to normal mode automatically.

Power cooling system

Do you want to be sure that the cold is distributed as evenly as possible in your refrigerator? If so, the PowerCooling system is what you need. The fan – as powerful as it is quiet – distributes the cold air efficiently throughout the entire refrigeration compartment.

3 bottle shelf

Now your bottles stay where they should. The 3 bottle shelf securely holds three bottles in your fridge ready to be used. The bottle shelf fits on every glass shelf and is therefore very flexible. And if you need the space for other reasons, simply take the shelf out of the fridge.

Super silent

Shhh – listen carefully. Your Liebherr is so quiet that you have to strain your ears to hear it. How is this achieved? All refrigeration components such as compressors, valves, fans and evaporators are optimised and perfectly adapted to one another. This means you only hear what you want to hear in your kitchen.

FreshAir activated charcoal filter

The smell of some foods is sometimes less pleasant. However, this is no problem for your Liebherr. Thanks to FreshAir activated carbon filters, there is always fresh air in the interior. The filter is located right on the air flow in the fan housing and neutralises odours as far as possible. The display reminds you to change the filter.

LED ceiling lighting

The LED ceiling lighting illuminates the interior from above – providing a good overview of your food. Another highlight: the LEDs are positioned in front of the glass shelves so that even a full refrigerator is well lit

Egg tray

Do you want to store eggs in your refrigerator safely and without a box? This is no problem with the egg tray. This will store up to 10 chicken eggs, keeping them stable and protected, and well cooled. The tray fits both in the inside door and on the glass shelves.

VarioSafe

Do you want a clearly arranged place for small food items such as yoghurt pots, jam jars or tubes? Your Liebherr provides this with the VarioSafe. It not only creates order, but is also highly adaptable. Simply place the two-stage height-adjustable VarioSafe in the refrigerator where it suits you best.

Door shelf

Do you want a safe storage area for your drinks or food? And do you still want to reach them easily? Our height-adjustable door shelves offer you both – thanks to the safety glass shelves and stainless steel rails. The sliding and removable bottle holder also ensures that your bottles are held securely.

Replaceable door seal

Do you think the door seal on your Liebherr needs to be replaced after a few years? This is very easy to do yourself. The replaceable door seal can be removed in a few simple steps – and the new seal is just as easy to insert. As a result, this part of the refrigerator is always spotless and hygienically clean.

Separable glass shelf

If you store a carafe or tall container in the refrigerator, you don’t want to have to remove an entire glass shelf. And why should you? Because there are separable glass shelves. Simply slide the front half of the glass shelf under the back half. This allows you to place higher containers at the front and still have enough space for other food.

Dishwasher safe features

The features of your Liebherr are practical in two ways: Not only do they simplify everyday use, they are also very easy to clean. Does the butter dish, FlexSystem or ice cube tray need to be cleaned? Just put them in the dishwasher. Then you’ll have more time for other things.

Technical Data
General Product Information
Model typeIntegrated fridge-freezer with EasyFresh and NoFrost
GTIN4016803117636
Seriesplus
Output & consumption
Refrigerator compartment190 l
Refrigerator compartment190 l
Freezer compartment83 l
Climate classSN-T
Noise level34 dB
Voltage220-240 V ~
Frequency50-60 Hz
Connection rating1.4 A 183 W
Control & functions
ControlMonochrome LC display , touch display
Control unitTouch
Number of temperature zones3
Number of regulated refrigeration circuits2
Temperature displayFridge & freezing compartment
Front frame heatingRefrigerator and freezer compartment
SuperCoolAdjustable on appliance and via app
SuperFrostAdjustable on appliance and via app
Door alarm, coolingAdjustable on appliance and via app
Door alarm, freezingAdjustable on appliance and via app
BottleTimerAdjustable on app
IceCubeTimer
NightModeAdjustable on app
Display lockAdjustable on appliance
Refrigerator Compartment
Adjustable temperature range, refrigerator compartment+2 °C to +9 °C
Moisture regulationDuoCooling
Refrigerator compartment climate zonesEasyFresh
Defrosting methodautomatic
Forced air cooling
FreshAir filterin valve
Pull-out system drawer, refrigerator compartmentIntegrated drawer guide
SoftSystemSoftSystem
Illumination cooling compartmentLED ceiling lighting
Number of storage shelves, refrigerator compartment6
Of which separable1
of which height-adjustable5
VarioSafe
OpenStage drawers
Bottle storage3-bottle shelf
Bottle rack1
Number of can racks2
VarioBox
VarioBoxes0
Egg tray10 eggs
Type of door rack Cooling compartmentBottle and can rack
Height-adjustable inner door shelfGradual adjustment
Freezer Compartment
Temperature range freezer compartment-15 °C to -26 °C
Cooling technologyNoFrost
Freezer compartment positionBottom
Defrosting methodautomatic
Storage time in case of fault according to GS *9 h
Freezing capacity in 24 hours according to GS *6.00 kg / 24h
No. of drawers in freezer compartment3
FrostSafeDrawers closed on all sides with transparent front
Drawer pull-out system, freezer compartmentDrawer on safety glass
Interior light, freezer compartment
VarioSpace
IceMakerNo
IceMaker safe lighting
Ice cube tray
Number of ice cube trays1
Number of water filters0
Freezer tray0
Star-rating4
Design & materials
Dry rear panel
Material dry back wallstainless steel with SmartSteel
Inner door décor
Material inner door rackWhite plastic
Storage shelf material, refrigerator compartmentGlass
Material of adjustable shelves in the freezer compartmentGlass
Door materialSteel
Setup & installation
Type of installationDesigned for integrated use
Door assemblyFixed door
Max. kitchen unit door weight18/12
Door hingesRight reversible
Door hinge replacementPossible for customer
Door opening angle115°
Door sealReplaceable
Height-adjustable feet2
Levelling bars
Number of levelling bars2
VentilationVentilation grates
Plug typeAustralia
Connector cable (length)2,200 mm
Specifications
Aperture dimensions height/width/depth177.2 - 178.8 / 56 - 57 / 55.0 cm
Height / Width / Depth (with packaging)1,829.0 / 572.0 / 622.0 mm
Dimensions H/W/D177 / 55.9 / 54.6 cm
Weight (without packaging)66.9 kg
Weight (with packaging)74.4 kg
Weight 74.4 kg
