Your hood always clean

Decorative filters with 12 layers ready to absorb up to 98% of grease and helping you to keep your hood clean. And you can wash the filters in the dishwasher.





Maximum efficiency with lower consumption

Our hoods have 4A Energy Class so will reduce your next electric bill significantly.





Extraction from any angle

Teka hoods have optimal absorption capacity by extraction to enjoy your kitchen free of smoke and odors.





Ambient lighting: adjust the light temperature and intensity to your kitchen

LED lighting bars is our best tool to provide light to a bigger area over the cooking zone, and being more efficient and environmentally friendly at the same time.

Technical details

  • Decorative horizontal hood
  • Electronic control with display
  • EcoPower motor
  • 3 speeds + 1 intensive
  • Free Outlet exhaust capacity (m3/h): 795
  • Intensive speed exhaust capacity (m3/h):740
  • Max speed exhaust capacity (m3/h): 586
  • Min speed exhaust capacity (m3/h): 306
  • Intensive speed sound level (dBA): 60
  • Max speed sound level (dBA): 55
  • Min speed sound level (dBA): 54
  • 1 LED lamp
  • 3 Stainless Steel filters with 12 layers
  • Stop delay timer
  • Filter saturation indicator
  • Operating pilot light
  • Exchangeable front panel
  • Anti-return valve included
  • Outlet reduction included
Interior measurements
  • Inner Height (mm): 955
General measures
  • Product height (mm): 670-1000
  • Product width (mm): 900
  • Product depth (mm): 480
  • Net weight (Kg): 15,33
Features
  • Certificates: CE; CB; Rohs
  • Ø Outlet (mm): 150
  • Type of inner light: LED
  • Inside light Consumption (W): 1 7
  • Plug type: Schuko plug
  • Power rate (V): 230
  • Frequency (Hz): 50
  • Total hood power (W): 287
  • Number of motors: 1
  • Motor power (W): 280
  • Air flow (Qmin) m3/h: 352
  • Air flow (Qmax): 651
  • Air flow (Qboost): 760
Accessories
  • Anti Return valve: Yes
  • Outlet reduction: Yes
  • Outlet extension: No
  • Optional Charcoal Filter: C1RTK
  • Regenerative charcoal filter: R1RTK
  • Conventional recirculation kit (opt) - w/tube cover: CFH 15200 L3C
  • Regenerative recirculation kit (opt) - w/tube cover: RFH 15200 L3C
Models
  • Number of filters: 3
  • Filter description: Stainless Steel filters MMX
  • Control panel: Touch Control (Glass Front) white display
  • Stop delay timer: Yes
  • Filter saturation indicator: Yes
  • Time clock: Yes
  • Number of speeds: 3+1
